H11AA4S1(TA)-V
Everlight Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 5KV TRANS W/BASE 6SMD
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet H11AA4S1(TA)-V Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$0.525
- 4,000$0.49528
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Number of Channels:1
- Voltage - Isolation:5000Vrms
- Current Transfer Ratio (Min):100% @ 10mA
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):10µs, 10µs (Max)
- Rise / Fall Time (Typ):10µs, 10µs (Max)
- Input Type:AC, DC
- Output Type:Transistor with Base
- Voltage - Output (Max):80V
- Current - Output / Channel:-
- Voltage - Forward (Vf) (Typ):1.2V
- Current - DC Forward (If) (Max):60 mA
- Vce Saturation (Max):400mV
- Operating Temperature:-55°C ~ 100°C
- Mounting Type:Surface Mount
- Package / Case:6-SMD, Gull Wing
- Supplier Device Package:6-SMD
