6N139-V

Technical Details

• Series:-
• Package:Tube
• Part Status:Active
• Number of Channels:1
• Voltage - Isolation:5000Vrms
• Current Transfer Ratio (Min):500% @ 1.6mA
• Current Transfer Ratio (Max):-
• Turn On / Turn Off Time (Typ):200ns, 1.7µs
• Rise / Fall Time (Typ):-
• Input Type:DC

• Output Type:Darlington with Base
• Voltage - Output (Max):18V
• Current - Output / Channel:60mA
• Voltage - Forward (Vf) (Typ):1.3V
• Current - DC Forward (If) (Max):20 mA
• Vce Saturation (Max):-
• Operating Temperature:-40°C ~ 85°C
• Mounting Type:Through Hole
• Package / Case:8-DIP (0.300", 7.62mm)
• Supplier Device Package:8-DIP
