ILD1-X001

Technical Details

• Series:-
• Package:Tube
• Part Status:Active
• Number of Channels:2
• Voltage - Isolation:5300Vrms
• Current Transfer Ratio (Min):20% @ 10mA
• Current Transfer Ratio (Max):300% @ 10mA
• Turn On / Turn Off Time (Typ):700ns, 1.4µs
• Rise / Fall Time (Typ):1.9µs, 1.4µs
• Input Type:DC

• Output Type:Transistor
• Voltage - Output (Max):50V
• Current - Output / Channel:50mA
• Voltage - Forward (Vf) (Typ):1.25V
• Current - DC Forward (If) (Max):60 mA
• Vce Saturation (Max):400mV
• Operating Temperature:-40°C ~ 100°C
• Mounting Type:Through Hole
• Package / Case:8-DIP (0.300", 7.62mm)
• Supplier Device Package:8-DIP
