PS2561DL-1Y-W-A
Renesas Electronics America
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 5KV TRANSISTOR
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet PS2561DL-1Y-W-A Datasheet
-
ECAD Model
- Share
In Stock: 270
Can ship immediately
Pricing:
- 1$0.73
- 7,150$0.196
Quote It
Technical Details
- Series:NEPOC
- Package:Tube
- Part Status:Active
- Number of Channels:1
- Voltage - Isolation:5000Vrms
- Current Transfer Ratio (Min):130% @ 5mA
- Current Transfer Ratio (Max):260% @ 5mA
- Turn On / Turn Off Time (Typ):-
- Rise / Fall Time (Typ):3µs, 5µs
- Input Type:DC
- Output Type:Transistor
- Voltage - Output (Max):80V
- Current - Output / Channel:50mA
- Voltage - Forward (Vf) (Typ):1.2V
- Current - DC Forward (If) (Max):40 mA
- Vce Saturation (Max):300mV
- Operating Temperature:-55°C ~ 110°C
- Mounting Type:Surface Mount
- Package / Case:4-SMD, Gull Wing
- Supplier Device Package:4-SMD
