TLP590B(C,F)
Toshiba Electronic Devices and Storage Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISOLATOR 2.5KV PHVOLT 6-DIP
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet TLP590B(C,F) Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$2.3372
- 50$2.3372
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Channels:1
- Voltage - Isolation:2500Vrms
- Current Transfer Ratio (Min):-
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):200µs, 1ms
- Rise / Fall Time (Typ):-
- Input Type:DC
- Output Type:Photovoltaic
- Voltage - Output (Max):7V
- Current - Output / Channel:12µA
- Voltage - Forward (Vf) (Typ):1.4V
- Current - DC Forward (If) (Max):50 mA
- Vce Saturation (Max):-
- Operating Temperature:-55°C ~ 125°C
- Mounting Type:Through Hole
- Package / Case:6-DIP (0.300", 7.62mm), 5 Leads
- Supplier Device Package:6-DIP, 5 Lead
