HCNR201#500
Broadcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 5KV LINEAR PHVOLT 8DIPGW
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet HCNR201#500 Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$3.27073
- 1,500$3.0856
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Number of Channels:1
- Voltage - Isolation:5000Vrms
- Current Transfer Ratio (Min):0.36% @ 10mA
- Current Transfer Ratio (Max):0.72% @ 10mA
- Turn On / Turn Off Time (Typ):-
- Rise / Fall Time (Typ):-
- Input Type:DC
- Output Type:Photovoltaic, Linearized
- Voltage - Output (Max):-
- Current - Output / Channel:-
- Voltage - Forward (Vf) (Typ):1.6V
- Current - DC Forward (If) (Max):25 mA
- Vce Saturation (Max):-
- Operating Temperature:-55°C ~ 100°C
- Mounting Type:Surface Mount
- Package / Case:8-SMD, Gull Wing
- Supplier Device Package:8-DIP Gull Wing
