MOC8020W
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 5.3KV DARLINGTON 6-DIP
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet MOC8020W Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Channels:1
- Voltage - Isolation:5300Vrms
- Current Transfer Ratio (Min):500% @ 10mA
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):3.5µs, 95µs
- Rise / Fall Time (Typ):-
- Input Type:DC
- Output Type:Darlington
- Voltage - Output (Max):50V
- Current - Output / Channel:150mA
- Voltage - Forward (Vf) (Typ):1.15V
- Current - DC Forward (If) (Max):60 mA
- Vce Saturation (Max):2V
- Operating Temperature:-55°C ~ 100°C
- Mounting Type:Through Hole
- Package / Case:6-DIP (0.400", 10.16mm)
- Supplier Device Package:6-DIP
