HCPL0730R1
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOCOUPLER DARL 2CHAN 8SOIC
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet HCPL0730R1 Datasheet
-
ECAD Model
- Share
In Stock: 123
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Number of Channels:2
- Voltage - Isolation:2500Vrms
- Current Transfer Ratio (Min):300% @ 1.6mA
- Current Transfer Ratio (Max):5000% @ 1.6mA
- Turn On / Turn Off Time (Typ):2µs, 7µs
- Rise / Fall Time (Typ):-
- Input Type:DC
- Output Type:Darlington
- Voltage - Output (Max):7V
- Current - Output / Channel:60mA
- Voltage - Forward (Vf) (Typ):1.35V
- Current - DC Forward (If) (Max):20 mA
- Vce Saturation (Max):-
- Operating Temperature:-40°C ~ 85°C
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SOIC
