- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISOLATOR 5KV 2CH TRANS 8-DIP
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet TLP626-2(F) Datasheet
-
ECAD Model
- Share
In Stock: 162
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Number of Channels:2
- Voltage - Isolation:5000Vrms
- Current Transfer Ratio (Min):100% @ 1mA
- Current Transfer Ratio (Max):1200% @ 1mA
- Turn On / Turn Off Time (Typ):10µs, 8µs
- Rise / Fall Time (Typ):8µs, 8µs
- Input Type:AC, DC
- Output Type:Transistor
- Voltage - Output (Max):55V
- Current - Output / Channel:50mA
- Voltage - Forward (Vf) (Typ):1.15V
- Current - DC Forward (If) (Max):50 mA
- Vce Saturation (Max):400mV
- Operating Temperature:-55°C ~ 100°C
- Mounting Type:Through Hole
- Package / Case:8-DIP (0.300", 7.62mm)
- Supplier Device Package:8-DIP
