CNC7S101Y
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISOLTR 5KV TRANSISTOR 4-DIL
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet CNC7S101Y Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Number of Channels:1
- Voltage - Isolation:5000Vrms
- Current Transfer Ratio (Min):20% @ 1mA
- Current Transfer Ratio (Max):300% @ 1mA
- Turn On / Turn Off Time (Typ):-
- Rise / Fall Time (Typ):4µs, 3µs
- Input Type:AC, DC
- Output Type:Transistor
- Voltage - Output (Max):80V
- Current - Output / Channel:50mA
- Voltage - Forward (Vf) (Typ):1.35V
- Current - DC Forward (If) (Max):50 mA
- Vce Saturation (Max):200mV
- Operating Temperature:-30°C ~ 100°C
- Mounting Type:Through Hole
- Package / Case:4-DIP (0.300", 7.62mm)
- Supplier Device Package:4-DIL
