HCPL2503SDV
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 2.5KV TRANS W/BASE 8SMD
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet HCPL2503SDV Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- Number of Channels:1
- Voltage - Isolation:2500Vrms
- Current Transfer Ratio (Min):12% @ 16mA
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):450ns, 300ns
- Rise / Fall Time (Typ):-
- Input Type:DC
- Output Type:Transistor with Base
- Voltage - Output (Max):20V
- Current - Output / Channel:8mA
- Voltage - Forward (Vf) (Typ):1.45V
- Current - DC Forward (If) (Max):25 mA
- Vce Saturation (Max):-
- Operating Temperature:-55°C ~ 100°C
- Mounting Type:Surface Mount
- Package / Case:8-SMD, Gull Wing
- Supplier Device Package:8-SMD
