ILQ55-X007
Vishay / Semiconductor - Opto Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 5.3KV 4CH DARL 16SMD
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet ILQ55-X007 Datasheet
-
ECAD Model
- Share
In Stock: 167
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Channels:4
- Voltage - Isolation:5300Vrms
- Current Transfer Ratio (Min):100% @ 10mA
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):-
- Rise / Fall Time (Typ):10µs, 35µs
- Input Type:DC
- Output Type:Darlington
- Voltage - Output (Max):55V
- Current - Output / Channel:125mA
- Voltage - Forward (Vf) (Typ):1.25V
- Current - DC Forward (If) (Max):60 mA
- Vce Saturation (Max):1V
- Operating Temperature:-55°C ~ 100°C
- Mounting Type:Surface Mount
- Package / Case:16-SMD, Gull Wing
- Supplier Device Package:16-SMD
