IL300-EF-X009
Vishay / Semiconductor - Opto Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISO 5.3KV PHVOLT 8SMD
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet IL300-EF-X009 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Channels:1
- Voltage - Isolation:5300Vrms
- Current Transfer Ratio (Min):-
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):-
- Rise / Fall Time (Typ):1µs, 1µs
- Input Type:DC
- Output Type:Photovoltaic, Linearized
- Voltage - Output (Max):500mV
- Current - Output / Channel:70µA (Typ)
- Voltage - Forward (Vf) (Typ):1.25V
- Current - DC Forward (If) (Max):60 mA
- Vce Saturation (Max):-
- Operating Temperature:-55°C ~ 100°C
- Mounting Type:Surface Mount
- Package / Case:8-SMD, Gull Wing
- Supplier Device Package:8-SMD
