TCED1100G
Vishay / Semiconductor - Opto Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionOPTOISOLATOR 5KV TRANS 4DIP
- CategoryOptoisolators - Transistor, Photovoltaic Output
- Datasheet TCED1100G Datasheet
-
ECAD Model
- Share
In Stock: 174
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Number of Channels:1
- Voltage - Isolation:5000Vrms
- Current Transfer Ratio (Min):600% @ 1mA
- Current Transfer Ratio (Max):-
- Turn On / Turn Off Time (Typ):-
- Rise / Fall Time (Typ):300µs, 250µs
- Input Type:DC
- Output Type:Transistor
- Voltage - Output (Max):35V
- Current - Output / Channel:80mA
- Voltage - Forward (Vf) (Typ):1.15V
- Current - DC Forward (If) (Max):60 mA
- Vce Saturation (Max):1V
- Operating Temperature:-40°C ~ 100°C
- Mounting Type:Through Hole
- Package / Case:4-DIP (0.400", 10.16mm)
- Supplier Device Package:4-DIP
