ADG904BRU-REEL7
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description4:1 MUX/SP4T
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG904BRU-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 10,077
Can ship immediately
Pricing:
- 1$2.32
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Switch Circuit:SP4T
- Multiplexer/Demultiplexer Circuit:4:1
- Number of Circuits:1
- On-State Resistance (Max):-
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):1.65V ~ 2.75V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):10ns, 16ns
- -3db Bandwidth:2.5GHz
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):2pF
- Current - Leakage (IS(off)) (Max):1µA
- Crosstalk:-58dB @ 100MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:20-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:20-TSSOP
