MAX4551ESE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionQUAD SPST ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4551ESE Datasheet
-
ECAD Model
- Share
In Stock: 1,948
Can ship immediately
Pricing:
- 1$2.4
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):120Ohm
- Channel-to-Channel Matching (ΔRon):1Ohm
- Voltage - Supply, Single (V+):2V ~ 12V
- Voltage - Supply, Dual (V±):±2V ~ 6V
- Switch Time (Ton, Toff) (Max):110ns, 90ns
- -3db Bandwidth:-
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):3.5pF, 3pF
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-90dB @ 100kHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SOIC
