DG419DY
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDG419, SPDT ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet DG419DY Datasheet
-
ECAD Model
- Share
In Stock: 16,939
Can ship immediately
Pricing:
- 1$2.53
- 500$1.54
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:1
- On-State Resistance (Max):35Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):12V
- Voltage - Supply, Dual (V±):±15V
- Switch Time (Ton, Toff) (Max):175ns, 145ns
- -3db Bandwidth:-
- Charge Injection:60pC
- Channel Capacitance (CS(off), CD(off)):8pF, 8pF
- Current - Leakage (IS(off)) (Max):250pA
- Crosstalk:-
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:8-SOIC
