MAX393CUE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionQUAD, SPST ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX393CUE Datasheet
-
ECAD Model
- Share
In Stock: 3,178
Can ship immediately
Pricing:
- 1$2.72
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NO/NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):35Ohm
- Channel-to-Channel Matching (ΔRon):300mOhm
- Voltage - Supply, Single (V+):3V ~ 15V
- Voltage - Supply, Dual (V±):±3V ~ 8V
- Switch Time (Ton, Toff) (Max):130ns, 75ns
- -3db Bandwidth:-
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):9pF, 9pF
- Current - Leakage (IS(off)) (Max):100pA
- Crosstalk:-85dB @ 1MHz
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
