HI4P0201-5
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSPST, 4 FUNC, 1 CHANNEL, CMOS
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet HI4P0201-5 Datasheet
-
ECAD Model
- Share
In Stock: 1,068
Can ship immediately
Pricing:
- 1$2.83
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):80Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±15V
- Switch Time (Ton, Toff) (Max):240ns, 500ns (Typ)
- -3db Bandwidth:-
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):5.5pF, 5.5pF
- Current - Leakage (IS(off)) (Max):50nA
- Crosstalk:-
- Operating Temperature:0°C ~ 75°C (TA)
- Mounting Type:Surface Mount
- Package / Case:20-LCC (J-Lead)
- Supplier Device Package:20-PLCC (9x9)
