MAX4602CPE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionQUAD, SPST ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 163
Can ship immediately
Pricing:
- 1$3.12
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):2.5Ohm
- Channel-to-Channel Matching (ΔRon):100mOhm
- Voltage - Supply, Single (V+):4.5V ~ 36V
- Voltage - Supply, Dual (V±):±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):250ns, 350ns
- -3db Bandwidth:-
- Charge Injection:120pC
- Channel Capacitance (CS(off), CD(off)):55pF, 55pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-59dB @ 1MHz
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
