DG1413EEN-T1-GE4
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH SPST QUAD 16QFN
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet DG1413EEN-T1-GE4 Datasheet
-
ECAD Model
- Share
In Stock: 7,660
Can ship immediately
Pricing:
- 1$6.31
- 2,500$3.1357
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Switch Circuit:SPST - NO/NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):1.5Ohm
- Channel-to-Channel Matching (ΔRon):40mOhm
- Voltage - Supply, Single (V+):4.5V ~ 24V
- Voltage - Supply, Dual (V±):±4.5V ~ 15V
- Switch Time (Ton, Toff) (Max):140ns, 110ns
- -3db Bandwidth:150MHz
- Charge Injection:-41pC
- Channel Capacitance (CS(off), CD(off)):24pF, 23pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-104dB @ 1MHz
- Operating Temperature:-40°C ~ 125°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-VQFN Exposed Pad
- Supplier Device Package:16-QFN (4x4)
