MAX4609ESE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionQUAD, SPST ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet MAX4609ESE Datasheet
-
ECAD Model
- Share
In Stock: 909
Can ship immediately
Pricing:
- 1$4.08
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NO/NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:2
- On-State Resistance (Max):2.5Ohm
- Channel-to-Channel Matching (ΔRon):50mOhm
- Voltage - Supply, Single (V+):4.5V ~ 36V
- Voltage - Supply, Dual (V±):±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):110ns, 150ns
- -3db Bandwidth:-
- Charge Injection:45pC
- Channel Capacitance (CS(off), CD(off)):64pF, 64pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-66dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SOIC
