MAX308CPE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description8-CHANNEL ANALOG MUX
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 2,253
Can ship immediately
Pricing:
- 1$4.25
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:8:1
- Number of Circuits:1
- On-State Resistance (Max):100Ohm
- Channel-to-Channel Matching (ΔRon):1.5Ohm
- Voltage - Supply, Single (V+):5V ~ 30V
- Voltage - Supply, Dual (V±):±5V ~ 20V
- Switch Time (Ton, Toff) (Max):150ns, 150ns
- -3db Bandwidth:-
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):3pF, 26pF
- Current - Leakage (IS(off)) (Max):750pA
- Crosstalk:-92dB @ 100kHz
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
