HI9P0509-5Z96
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIFFERENTIAL MUX, 4 CHANNEL
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet HI9P0509-5Z96 Datasheet
-
ECAD Model
- Share
In Stock: 2,087
Can ship immediately
Pricing:
- 1$5.96
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Switch Circuit:SP4T
- Multiplexer/Demultiplexer Circuit:4:1
- Number of Circuits:2
- On-State Resistance (Max):400Ohm
- Channel-to-Channel Matching (ΔRon):20Ohm
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±15V
- Switch Time (Ton, Toff) (Max):250ns, 250ns (Typ)
- -3db Bandwidth:-
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):10pF, 12pF
- Current - Leakage (IS(off)) (Max):30pA (Typ)
- Crosstalk:-
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SOIC
