IH5143CWE
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCMOS ANALOG SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 578
Can ship immediately
Pricing:
- 1$6.99
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:2
- On-State Resistance (Max):100Ohm
- Channel-to-Channel Matching (ΔRon):5Ohm
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±4.5V ~ 18V
- Switch Time (Ton, Toff) (Max):300ns, 150ns
- -3db Bandwidth:-
- Charge Injection:15pC
- Channel Capacitance (CS(off), CD(off)):-
- Current - Leakage (IS(off)) (Max):100nA
- Crosstalk:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:16-SOIC
