HI3-0201HS-5
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSPST, 4 FUNC, 1 CHANNEL, CMOS, P
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet HI3-0201HS-5 Datasheet
-
ECAD Model
- Share
In Stock: 4,301
Can ship immediately
Pricing:
- 1$8.43
- 2,500$2.92536
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):50Ohm
- Channel-to-Channel Matching (ΔRon):1.5Ohm
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±15V
- Switch Time (Ton, Toff) (Max):50ns, 50ns
- -3db Bandwidth:-
- Charge Injection:10pC
- Channel Capacitance (CS(off), CD(off)):10pF, 10pF
- Current - Leakage (IS(off)) (Max):10nA
- Crosstalk:-86dB @ 100kHz
- Operating Temperature:0°C ~ 75°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
