ADG526AKR-REEL
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSINGLE-ENDED MUX,16 CHANNEL
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG526AKR-REEL Datasheet
-
ECAD Model
- Share
In Stock: 2,070
Can ship immediately
Pricing:
- 1$8.98
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:16:1
- Number of Circuits:1
- On-State Resistance (Max):450Ohm
- Channel-to-Channel Matching (ΔRon):22.5Ohm
- Voltage - Supply, Single (V+):10.8V ~ 16.5V
- Voltage - Supply, Dual (V±):±10.8V ~ 16.5V
- Switch Time (Ton, Toff) (Max):300ns, 300ns
- -3db Bandwidth:-
- Charge Injection:4pC
- Channel Capacitance (CS(off), CD(off)):5pF, 44pF
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:28-SOIC (0.295", 7.50mm Width)
- Supplier Device Package:28-SOIC
