M20001G-14
Metelics (MACOM Technology Solutions)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH SPDT 15.5 DUAL 16QFN
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet M20001G-14 Datasheet
-
ECAD Model
- Share
In Stock: 3,043
Can ship immediately
Pricing:
- 1$19.3
- 3,000$12.6
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:2
- On-State Resistance (Max):15.5Ohm
- Channel-to-Channel Matching (ΔRon):300mOhm
- Voltage - Supply, Single (V+):2.97V ~ 3.63V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):-
- -3db Bandwidth:6GHz
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):-
- Current - Leakage (IS(off)) (Max):-
- Crosstalk:-30dB @ 6GHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-VFQFN Exposed Pad
- Supplier Device Package:16-QFN (3x3)
