74HCT4316D,118
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionNOW NEXPERIA 74HCT4316D - SPST,
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet 74HCT4316D,118 Datasheet
-
ECAD Model
- Share
In Stock: 12,715
Can ship immediately
Pricing:
- 1$0.16
- 2,500$0.06219
- 5,000$0.0579
- 12,500$0.05576
- 25,000$0.05361
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):135Ohm
- Channel-to-Channel Matching (ΔRon):6Ohm
- Voltage - Supply, Single (V+):4.5V ~ 5.5V
- Voltage - Supply, Dual (V±):±1V ~ 5V
- Switch Time (Ton, Toff) (Max):42ns, 34ns
- -3db Bandwidth:160MHz
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):3.5pF
- Current - Leakage (IS(off)) (Max):100nA
- Crosstalk:-60dB @ 1MHz
- Operating Temperature:-40°C ~ 125°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SO
