TS5A3154DCURG4
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description0.9-OHM SPDT ANALOG SWITCH 5-V/3
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 15,102
Can ship immediately
Pricing:
- 1$0.26
- 3,000$0.2552
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:1
- On-State Resistance (Max):900mOhm
- Channel-to-Channel Matching (ΔRon):50mOhm
- Voltage - Supply, Single (V+):1.65V ~ 5.5V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):16ns, 15ns
- -3db Bandwidth:100MHz
- Charge Injection:12pC
- Channel Capacitance (CS(off), CD(off)):19pF, 36pF
- Current - Leakage (IS(off)) (Max):20nA
- Crosstalk:-64dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:8-VFSOP (0.091", 2.30mm Width)
- Supplier Device Package:8-VSSOP
