TS3DS26227YZTR

Technical Details

• Series:-
• Package:Bulk
• Part Status:Active
• Switch Circuit:SPDT
• Multiplexer/Demultiplexer Circuit:2:1
• Number of Circuits:2
• On-State Resistance (Max):5Ohm
• Channel-to-Channel Matching (ΔRon):50mOhm
• Voltage - Supply, Single (V+):2.3V ~ 3.6V
• Voltage - Supply, Dual (V±):-

• Switch Time (Ton, Toff) (Max):9ns, 4ns
• -3db Bandwidth:80MHz
• Charge Injection:5.5pC
• Channel Capacitance (CS(off), CD(off)):3.5pF
• Current - Leakage (IS(off)) (Max):5nA
• Crosstalk:-39dB @ 200MHz
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:12-UFBGA, DSBGA
• Supplier Device Package:12-DSBGA (1.9x1.4)
