MAX4595DBVR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMAX4595 SINGLE-CHANNEL 10-OHM SP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 243,695
Can ship immediately
Pricing:
- 1$0.4
- 3,000$0.3766
- 6,000$0.35777
- 15,000$0.34432
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:1
- On-State Resistance (Max):10Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):2.4V ~ 5.5V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):35ns, 40ns
- -3db Bandwidth:300MHz
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):8pF, 8pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:SC-74A, SOT-753
- Supplier Device Package:SOT-23-5
