CD4051BCMTC
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSINGLE-ENDED MUX, 8 CHANNEL
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet CD4051BCMTC Datasheet
-
ECAD Model
- Share
In Stock: 710
Can ship immediately
Pricing:
- 1$0.22
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:8:1
- Number of Circuits:1
- On-State Resistance (Max):240Ohm
- Channel-to-Channel Matching (ΔRon):5Ohm
- Voltage - Supply, Single (V+):5V ~ 15V
- Voltage - Supply, Dual (V±):±2.5V ~ 7.5V
- Switch Time (Ton, Toff) (Max):320ns, 150ns
- -3db Bandwidth:40MHz
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):-
- Current - Leakage (IS(off)) (Max):50nA
- Crosstalk:-40dB @ 3MHz
- Operating Temperature:-55°C ~ 125°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
