SN74LV4051APWT

Technical Details

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Switch Circuit:-
• Multiplexer/Demultiplexer Circuit:8:1
• Number of Circuits:1
• On-State Resistance (Max):75Ohm
• Channel-to-Channel Matching (ΔRon):1.3Ohm
• Voltage - Supply, Single (V+):2V ~ 5.5V
• Voltage - Supply, Dual (V±):-

• Switch Time (Ton, Toff) (Max):14ns, 14ns
• -3db Bandwidth:35MHz
• Charge Injection:-
• Channel Capacitance (CS(off), CD(off)):0.5pF, 23.4pF
• Current - Leakage (IS(off)) (Max):100nA
• Crosstalk:-
• Operating Temperature:-40°C ~ 85°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-TSSOP (0.173", 4.40mm Width)
• Supplier Device Package:16-TSSOP
