MAX4514CPA

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Switch Circuit:SPST - NO
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:1
• On-State Resistance (Max):20Ohm
• Channel-to-Channel Matching (ΔRon):-
• Voltage - Supply, Single (V+):2V ~ 12V
• Voltage - Supply, Dual (V±):-

• Switch Time (Ton, Toff) (Max):150ns, 100ns
• -3db Bandwidth:-
• Charge Injection:2pC
• Channel Capacitance (CS(off), CD(off)):14pF, 14pF
• Current - Leakage (IS(off)) (Max):1nA
• Crosstalk:-
• Operating Temperature:0°C ~ 70°C (TA)
• Mounting Type:Through Hole
• Package / Case:8-DIP (0.300", 7.62mm)
• Supplier Device Package:8-PDIP
