LMS4684ITL/NOPB
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH DUAL SPDT 12USMD
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 681
Can ship immediately
Pricing:
- 1$1.48
- 500$1.32826
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:2
- On-State Resistance (Max):800mOhm
- Channel-to-Channel Matching (ΔRon):1.11mOhm
- Voltage - Supply, Single (V+):1.8V ~ 5.5V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):60ns, 40ns
- -3db Bandwidth:-
- Charge Injection:200pC
- Channel Capacitance (CS(off), CD(off)):-
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-72dB @ 100kHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:12-WFBGA
- Supplier Device Package:12-µSMD (1.59x2.33)
