ADG452BR-REEL
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionQUAD SPST SWITCH
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG452BR-REEL Datasheet
-
ECAD Model
- Share
In Stock: 215
Can ship immediately
Pricing:
- 1$3.38
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):5Ohm
- Channel-to-Channel Matching (ΔRon):100mOhm
- Voltage - Supply, Single (V+):12V
- Voltage - Supply, Dual (V±):±4.5V ~ 20V
- Switch Time (Ton, Toff) (Max):180ns, 140ns
- -3db Bandwidth:-
- Charge Injection:20pC
- Channel Capacitance (CS(off), CD(off)):37pF, 37pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-90dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SOIC
