AD7511DIKN/+
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPROTECTED ANALOG SWITCHES
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet AD7511DIKN/+ Datasheet
-
ECAD Model
- Share
In Stock: 269
Can ship immediately
Pricing:
- 1$5.99
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):100Ohm
- Channel-to-Channel Matching (ΔRon):1Ohm
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±15V
- Switch Time (Ton, Toff) (Max):180ns, 350ns (Typ)
- -3db Bandwidth:-
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):8pF, 1pF
- Current - Leakage (IS(off)) (Max):5nA
- Crosstalk:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-DIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
