TS3A44159TD2
Texas Instruments- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH QUAD SPDT DIE
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 207
Can ship immediately
Pricing:
- 1$9.35
- 70$7.59529
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:4
- On-State Resistance (Max):450mOhm
- Channel-to-Channel Matching (ΔRon):50mOhm
- Voltage - Supply, Single (V+):1.65V ~ 4.3V
- Voltage - Supply, Dual (V±):-
- Switch Time (Ton, Toff) (Max):23ns, 32ns
- -3db Bandwidth:35MHz
- Charge Injection:139pC
- Channel Capacitance (CS(off), CD(off)):50pF
- Current - Leakage (IS(off)) (Max):20nA
- Crosstalk:-73dB @ 100kHz
- Operating Temperature:25°C
- Mounting Type:Surface Mount
- Package / Case:Die
- Supplier Device Package:Die
