DG508BEN-T1-GE4
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MUX ANALOG SINGLE 8CH 16QFN
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet DG508BEN-T1-GE4 Datasheet
-
ECAD Model
- Share
In Stock: 184
Can ship immediately
Pricing:
- 1$2.35
- 3,000$0.97917
- 6,000$0.9429
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:8:1
- Number of Circuits:1
- On-State Resistance (Max):380Ohm
- Channel-to-Channel Matching (ΔRon):10Ohm
- Voltage - Supply, Single (V+):12V
- Voltage - Supply, Dual (V±):±5V ~ 20V
- Switch Time (Ton, Toff) (Max):250ns, 240ns
- -3db Bandwidth:250MHz
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):3pF, 13pF
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-88dB @ 1MHz
- Operating Temperature:-40°C ~ 125°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-WFQFN
- Supplier Device Package:16-miniQFN (1.8x2.6)
