ADG333ABRS-REEL
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSPDT, 4 FUNC, 1 CHANNEL, PDSO20
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG333ABRS-REEL Datasheet
-
ECAD Model
- Share
In Stock: 304
Can ship immediately
Pricing:
- 1$4.35
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Switch Circuit:SPDT
- Multiplexer/Demultiplexer Circuit:2:1
- Number of Circuits:4
- On-State Resistance (Max):45Ohm
- Channel-to-Channel Matching (ΔRon):5Ohm
- Voltage - Supply, Single (V+):3V ~ 30V
- Voltage - Supply, Dual (V±):±3V ~ 20V
- Switch Time (Ton, Toff) (Max):90ns, 80ns (Typ)
- -3db Bandwidth:-
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):7pF
- Current - Leakage (IS(off)) (Max):250pA
- Crosstalk:-85dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:20-SSOP (0.209", 5.30mm Width)
- Supplier Device Package:20-SSOP
