MPC507AP
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIFFERENTIAL MUX, 8 CHANNEL
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
-
ECAD Model
- Share
In Stock: 165
Can ship immediately
Pricing:
- 1$8.44
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:8:1
- Number of Circuits:2
- On-State Resistance (Max):1.5kOhm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±5V ~ 22V
- Switch Time (Ton, Toff) (Max):200ns, 250ns (Typ)
- -3db Bandwidth:-
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):5pF, 25pF
- Current - Leakage (IS(off)) (Max):500pA (Typ)
- Crosstalk:-
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Package / Case:28-DIP (0.600", 15.24mm)
- Supplier Device Package:28-PDIP
