AD7503KQ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSINGLE-ENDED MUX,8 CHANNEL
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet AD7503KQ Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$25.48
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:8:1
- Number of Circuits:1
- On-State Resistance (Max):300Ohm
- Channel-to-Channel Matching (ΔRon):12Ohm
- Voltage - Supply, Single (V+):-
- Voltage - Supply, Dual (V±):±15V
- Switch Time (Ton, Toff) (Max):800ns, 800ns (Typ)
- -3db Bandwidth:-
- Charge Injection:-
- Channel Capacitance (CS(off), CD(off)):5pF, 30pF
- Current - Leakage (IS(off)) (Max):2nA
- Crosstalk:-
- Operating Temperature:-25°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-CDIP (0.300", 7.62mm)
- Supplier Device Package:16-CDIP
