DG413LEDJ-GE3
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH QUAD SPST 16-DIP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet DG413LEDJ-GE3 Datasheet
-
ECAD Model
- Share
In Stock: 128
Can ship immediately
Pricing:
- 1$2.09392
- 500$1.97495
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Switch Circuit:SPST - NO/NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):26Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):3V ~ 16V
- Voltage - Supply, Dual (V±):±3V ~ 8V
- Switch Time (Ton, Toff) (Max):50ns, 30ns
- -3db Bandwidth:-
- Charge Injection:6.6pC
- Channel Capacitance (CS(off), CD(off)):5pF, 6pF
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-114dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Through Hole
- Package / Case:16-PowerDIP (0.300", 7.62mm)
- Supplier Device Package:16-PDIP
