ADG1308BRUZ-REEL7
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MULTIPLEXER 8X1 16TSSOP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG1308BRUZ-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 101
Can ship immediately
Pricing:
- 1$2.4
- 1,000$2.4
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:-
- Multiplexer/Demultiplexer Circuit:8:1
- Number of Circuits:1
- On-State Resistance (Max):210Ohm
- Channel-to-Channel Matching (ΔRon):5Ohm
- Voltage - Supply, Single (V+):5V ~ 16.5V
- Voltage - Supply, Dual (V±):±5V ~ 16.5V
- Switch Time (Ton, Toff) (Max):100ns, 100ns
- -3db Bandwidth:500MHz
- Charge Injection:2pC
- Channel Capacitance (CS(off), CD(off)):15pF, 20pF
- Current - Leakage (IS(off)) (Max):1nA
- Crosstalk:-80dB @ 1MHz
- Operating Temperature:-40°C ~ 105°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package:16-TSSOP
