ADG1422BCPZ-REEL7
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SW SPST 2.1OHM RON 10LFCSP
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG1422BCPZ-REEL7 Datasheet
-
ECAD Model
- Share
In Stock: 182
Can ship immediately
Pricing:
- 1$2.505
- 1,500$2.505
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Switch Circuit:SPST - NC
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:2
- On-State Resistance (Max):2.4Ohm
- Channel-to-Channel Matching (ΔRon):20mOhm
- Voltage - Supply, Single (V+):5V ~ 16.5V
- Voltage - Supply, Dual (V±):±4.5V ~ 16.5V
- Switch Time (Ton, Toff) (Max):145ns, 145ns
- -3db Bandwidth:180MHz
- Charge Injection:-5pC
- Channel Capacitance (CS(off), CD(off)):18pF, 22pF
- Current - Leakage (IS(off)) (Max):500pA
- Crosstalk:-74dB @ 1MHz
- Operating Temperature:-40°C ~ 125°C (TA)
- Mounting Type:Surface Mount
- Package / Case:10-VFDFN Exposed Pad, CSP
- Supplier Device Package:10-LFCSP-WD (3x3)
