MAX4700CWE+T

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• Switch Circuit:SPST - NO/NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):1.25Ohm
• Channel-to-Channel Matching (ΔRon):90mOhm
• Voltage - Supply, Single (V+):4.5V ~ 36V
• Voltage - Supply, Dual (V±):±4.5V ~ 20V

• Switch Time (Ton, Toff) (Max):275ns, 175ns
• -3db Bandwidth:-
• Charge Injection:550pC
• Channel Capacitance (CS(off), CD(off)):115pF, 115pF
• Current - Leakage (IS(off)) (Max):500pA
• Crosstalk:-65dB @ 1MHz
• Operating Temperature:0°C ~ 70°C (TA)
• Mounting Type:Surface Mount
• Package / Case:16-SOIC (0.295", 7.50mm Width)
• Supplier Device Package:16-SOIC
