LTC1393CS#TRPBF
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC MULTIPLEXER DUAL 4X1 16SOIC
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet LTC1393CS#TRPBF Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$4.29
- 2,500$4.19323
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SP4T
- Multiplexer/Demultiplexer Circuit:4:1
- Number of Circuits:2
- On-State Resistance (Max):70Ohm
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):2.7V
- Voltage - Supply, Dual (V±):±5V
- Switch Time (Ton, Toff) (Max):1.5µs, 1.2µs
- -3db Bandwidth:-
- Charge Injection:1pC
- Channel Capacitance (CS(off), CD(off)):3pF, 18pF
- Current - Leakage (IS(off)) (Max):5nA
- Crosstalk:-
- Operating Temperature:0°C ~ 70°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SOIC
