ADG512BRZ-REEL
Linear Technology (Analog Devices, Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionIC SWITCH QUAD SPST 16SOIC
- CategoryInterface - Analog Switches, Multiplexers, Demultiplexers
- Datasheet ADG512BRZ-REEL Datasheet
-
ECAD Model
- Share
In Stock: 194
Can ship immediately
Pricing:
- 1$4.55
- 2,500$3.91136
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Switch Circuit:SPST - NO
- Multiplexer/Demultiplexer Circuit:1:1
- Number of Circuits:4
- On-State Resistance (Max):30Ohm (Typ)
- Channel-to-Channel Matching (ΔRon):-
- Voltage - Supply, Single (V+):3V ~ 5.5V
- Voltage - Supply, Dual (V±):±4.5V ~ 5.5V
- Switch Time (Ton, Toff) (Max):200ns, 120ns (Typ)
- -3db Bandwidth:-
- Charge Injection:11pC
- Channel Capacitance (CS(off), CD(off)):9pF, 9pF
- Current - Leakage (IS(off)) (Max):100pA
- Crosstalk:-85dB @ 1MHz
- Operating Temperature:-40°C ~ 85°C (TA)
- Mounting Type:Surface Mount
- Package / Case:16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package:16-SOIC
