MAX324CUA+

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• Switch Circuit:SPST - NC
• Multiplexer/Demultiplexer Circuit:1:1
• Number of Circuits:2
• On-State Resistance (Max):60Ohm
• Channel-to-Channel Matching (ΔRon):800mOhm
• Voltage - Supply, Single (V+):2.7V ~ 16V
• Voltage - Supply, Dual (V±):-

• Switch Time (Ton, Toff) (Max):150ns, 100ns
• -3db Bandwidth:-
• Charge Injection:1pC
• Channel Capacitance (CS(off), CD(off)):9pF, 9pF
• Current - Leakage (IS(off)) (Max):100pA
• Crosstalk:-85dB @ 1MHz
• Operating Temperature:0°C ~ 70°C (TA)
• Mounting Type:Surface Mount
• Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
• Supplier Device Package:8-uMAX
